Siton LWT-80 Crawler Muck Loader
Single Power Wheel Mucking Loader
| Model | Unit | Single power | |
| LWT- 80/18T | |||
| Weight | Kg | 3800 | |
| Loading capacity | m³/h | 80 | |
| Drive mode | Electric (four wheels) | ||
| Digging width | mm | 2600 | |
| Digging height | mm | 1900 | |
| Digging distance (from dozer blade) | mm | 1300 | |
| Digging depth | mm | 430 | |
| Dumping height | mm | 1200 (Variable) | |
| Dumping distance | mm | 1150 (Variable) | |
| Traveling speed | m/s | 1.03/0.58 | |
| gradient | (°) | ≤15 (Hardstand) | |
| Rated working gradient | (°) | ≤8 | |
| Min.turning radius | m | ≤4 | |
| Conveyor speed | m/min | 39 | |
| Max.work pressure | Mpa | 11 | |
| Ground clearance | mm | ≤160 | |
| General power | KW | 18 | |
| Wheel base | mm | 1490 | |
| Wheel tread | mm | 1180 | |
| Max. meterial dimension(W×H) | mm | 400×300 | |
| Max.boom angle | (°) | ±30 | |
| Dimensions during operating | Length | mm | 6300 |
| Width | mm | 1500 | |
| Height | mm | 160 | |
| Adaptive tunnel dimension (W×H) | m | ≥2×2 | |
